General
Part No. 250.400
Dimensions (W x D x H) (mm) / (inch) 114 x 231 x 137/4.5“ x 9.1" x 5.4"
Weight (kg) Approx. 3.6
Cooling Low-noise fan
Electrical
Operating voltage, frequency 100 – 240 V ~, 50 – 60 Hz
Input voltage (V) 24
Power consumption (VA) Max. 80
Protection class II
Overvoltage category II
Lamp type 9 High power LED white
Lamp lifetime (h) 50.000
1
Light Output
Luminous flux (Im) 1.100
2
Color temperature (K) Approx. 5.600
Active light guide diameter (mm) / (inch) Max. 9/Max. 0.35"
Certification marks
Marking
EMC-class B
1 max. decline of light output to 70% of origin level
2 at the output of SCHOTT fiber optic light guide, 1-arm, flexible, Ø 9 mm active, length 1,000 mm
